Product Overview
Glass fiber filter element is a new type of liquid and air purification filter element, which is made by advanced technology with composite glass fiber membrane as filter medium. Composite glass fiber filter is the traditional ultra-fine glass fiber on both sides of the polypropylene fiber membrane, retained the ultra-fine glass fiber membrane high voidage, high flux, large cut-off capacity, good temperature and corrosion resistance, and so on, it is a kind of new filter element with excellent performance and wide use to overcome the disadvantages of low strength of glass fiber membrane, easy breakage and falling off under pressure.
Product characteristics
Hydrophilic filter membrane, with uniform pore diameter distribution, high porosity, high flow rate and particle retention rate
With good temperature resistance and acid-base resistance performance
Technical Specification
| Filter Element Size | Outer Diameter: 63 mm, 115 mmInner Diameter: 28 mm, 30 mm Length: 10″, 20″, 30″, 40″ |
| Filter Material | Polypropylene (PP), Absorbent Cotton, Fiberglass |
| Center Core Material | Polypropylene (PP), Stainless Steel |
| Filtration Accuracy | 1 μm, 5 μm, 10 μm, 20 μm, 30 μm, 50 μm, 75 μm, 100 μm |
Application Area
General drinking water pre-filtration treatment.
Filtering of acid-alkali liquid in the chemical process.
Filtering of chemical raw materials and organic solvents.
R.O Inverse osmosis front-filtration treatment.
Filtering of syrup, chocolate.
Filtering of the images with medicine liquid and ink.
Pre-filtration treatment of sterile water and ultra-pure water.
Industrial water, the filtration of electroplating liquid.
