Product Overview
MEDA solution activated Carbon Filter (alias: Activated Carbon Filter, TEG solution activated carbon filter, solution filter, rich amine solution activated carbon filter, poor amine solution activated carbon filter, triethylene glycol filter) is suitable for natural gas purification plant deacidification unit to filter MEDA solution and dehydration unit to filter TEG solution adsorption, it mainly adsorbs and removes hydrocarbon and organic acid impurities in MEDA solution and TEG solution to ensure the cleanliness of the solution in the system, can effectively avoid activated carbon into the system caused by solution foaming and other phenomena.
Technical Specification
| Operating pressure | 0.1 ~ 6.4 MPA |
| Operating temperature | -10~100 °C |
| Filtering accuracy | 5 ~ 50 μm |
| Filtering efficiency | 99.99% |
| Initial pressure drop | 0.1 bar |
| Impurity type | Hydrocarbon and organic acid |
| Impurity filter material | Activated Carbon |
Filter specification Location: mm
| Outside diameter | Internal diameter | Length |
| 230 | 88 | Customizes |
| 172 | 57 | Customizes |
| Other specifications and sizes can be customized according to the situation | ||
Application Area
It is mainly used for solution purification in natural gas purification plants, liquefied gas plants, chemical plants, iron and steel metallurgy plants, natural gas long-distance pipeline stations, medicine, light industry, machinery, environmental protection and other occasions.
