Product Overview
PE and PA sintering filter elements are mainly used for the filtration and sewage treatment of pure water, domestic water, beverage, medical treatment, electroplating solution, emulsion, detergent, acid and alkali solutions, which can not only filter out the suspended substances in the liquid, but also remove chlorine, organic impurities, color and odor in the liquid.
Product Features
Specification and dimensions of the filter element
| Diameter | 20, 25, 30, 35, 40, 45, 50, 60 |
| Length | 5″, 10″, 20″, 30″, 40″ |
| Large Diameter Option | Custom large-diameter filter element (Ø1000) available upon request |
| Filtration Accuracy | 0.3 μm, 0.45 μm, 1 μm, 3 μm, 5 μm, 10 μm, 20 μm, 30 μm, 40 μm, 50 μm |
Advantages
Characteristics and Performance
PE and PA filter element aperture is uniform distribution, strong acid resistance, strong alkali resistance, high temperature resistance, good mechanical performance, and strong organic solvent erosion resistance.The production of large water treatment equipment, can use automatic or manual recoil slag removal method, solid particle recycling can use dry slag removal, do not need to often replace the filter element, automatic operation, low filtration cost and other advantages, which are highly praised by users.
Operating Conditions
- 0-40℃ maximum operating pressure difference of 6bar
- 60℃ maximum operating pressure difference of 5bar
- 80℃ Maximum operating pressure difference of 4.5bar
- 120℃ maximum operating pressure difference of 4bar
Using ultra-high molecular weight polyethylene sintering molding, compact structure, strong, light quality, can withstand high filtration pressure, non-toxic and tasteless, and has good corrosion resistance to acid-alkali solvents.
